Automaatne ülekandelüliti (ATS) 32A, 19" 2U, 18xC13+2xC19 3m 16A, max 7360W
Tootekood:
MXL32A18C13C19
Kaubamärk:
Ühik:
tk
Laoseis:
Tarneaeg 5-30 päeva.
1157,89 €
Failid
18xIEC320C13 sockets outlet max. 10A/230VAC.
2xIEC320C19 sockets outlet max. 16A/230VAC.
Aluminium body, black powder coat.
Dimension without mounting brackets WxHxD: 442x86,6x140mm.
Horizontal mounting in 19” rack - 2U.
Supply cables H05VVF.3G4,0mm² black colour 2xIEC60309 blue 1-phase 32A/230V plugs. Standard length 2m.
Maximum current 32A (7360 W).
Mains voltage 2 x 230 VAC
Two power sources are connected to PDU. In case of disappearing basic power source PDU will automatically switch supplying on second source. After 10s from appearance of the basic source PDU automatically return to basic setting.
- time switching from basic to second power source: 15ms
- time switching from second to basic power source: 12ms
- delay time of return to basic source: 10s
Protection level IP20.
Declaration of Conformity CE.
2xIEC320C19 sockets outlet max. 16A/230VAC.
Aluminium body, black powder coat.
Dimension without mounting brackets WxHxD: 442x86,6x140mm.
Horizontal mounting in 19” rack - 2U.
Supply cables H05VVF.3G4,0mm² black colour 2xIEC60309 blue 1-phase 32A/230V plugs. Standard length 2m.
Maximum current 32A (7360 W).
Mains voltage 2 x 230 VAC
Two power sources are connected to PDU. In case of disappearing basic power source PDU will automatically switch supplying on second source. After 10s from appearance of the basic source PDU automatically return to basic setting.
- time switching from basic to second power source: 15ms
- time switching from second to basic power source: 12ms
- delay time of return to basic source: 10s
Protection level IP20.
Declaration of Conformity CE.
