Toitesiin 12xSchuko ,ampermeetriga, IP func, 3m -IEC60309 pistik, pikkus 732mm
Tootekood:
MXLJ08S123
Kaubamärk:
Ühik:
tk
Laoseis:
Tarneaeg 5-30 päeva.
309,38 €
12, 15 or 18 "schuko" sockets outlet (German standard) max. 16A/230VAC.
Socket 45° oriented.
Plastic elements colour: light-grey similar to RAL7035 or black similar to RAL9005.
Natural anodized aluminium body.
Dimension without mounting brackets: width 44mm, length/height according to the table, depth 44mm.
Vertical mounting in 19” rack.
Mounting brackets for installation in 4 orientations.
Supply cable H05VVF.3G1,5mm² in white or black colour terminated unischuko angled plug. Standard length up to 10m.
Maximum current 16A (3 680 W).
Mains voltage 230 VAC
AC ammeter with 3 digits LED display.
- Measurement range 0,1...16A.
- Measurement accurate ±2,5%.
Build-in web-server with monitoring of supply circuits, current load and temperature.
- Network interface: Ethernet RJ45 (Ethernet 10/100BaseT).
- RJ11 interface for optional temperature sensor
- Protocols: TCP/IP, HTTP, SNMP, SMTP, Syslog, DHCP.
Protection level IP20.
Declaration of Conformity CE.
