3 x Schuko sockets outlet (German standard) max. 16A/230VAC
3 x IEC320C13 sockets outlet max. 10A/230VAC
Schuko sockets 45° oriented.
Schuko sockets with protection against accidental contact.
Plastic elements colour: light-grey similar to RAL7035
Natural anodized aluminium body.
Dimensions without mounting brackets (WxHxD): 44x452x46mm
Vertical mounting in 19" rack - 0U
Mounting brackets for installation in 4 orientations
3-meter supply cables H05VV-F.3G1,0mm² in white and black colour
Supply cables terminated IEC320C14 plug 10A/230V.
Maximum current 10A (2300 W).
Two power sources are connected to PDU. In case of disappearing basic power source PDU will automatically switch supplying on second source. After 10s from appearance of the basic source PDU automatically return to basic setting.
time switching from basic to second power source: 15ms
time switching from second to basic power source: 12ms
delay time of return to basic source: 10s
Protection level IP20.
Declaration of Conformity CE.
