Vahekaabel CAT6A S/FTP 15,0m tööstuslahendustesse RAL6018
Tootekood:
TTL-1842-SK-15,0M
EAN:
4260424517461
Kaubamärk:
Pikkus:
15,0m
Standard:
CAT6A
Tüüp:
FTP
Värv:
Roheline
Ühik:
tk
Laoseis:
Tarneaeg 5-30 päeva.
175,00 €
Cat. 6a industrial Ethernet PUR patch cable, suitable for drag chain SF/FTP
This cat. 6a patch cable is compatible with drag chains and has been developed for applications in industrial areas that are subject to frequent movement and stress.
Robust finishing and a multi-layered cable design ensure high durability and excellent, stable data transmission.
Plug
Cable
Features
This cat. 6a patch cable is compatible with drag chains and has been developed for applications in industrial areas that are subject to frequent movement and stress.
Robust finishing and a multi-layered cable design ensure high durability and excellent, stable data transmission.
Plug
- Type: 2x cat. 6a RJ45 plug
- Anti-kink sleeve: moulded
- Colour: green, similar to RAL 6018
Cable
- Type: SF/FTP
- Design: 4x2
- Inner conductor diameter: 0.55 mm
- Double wire/wire insulation
- Copper, tin-plated
- Shielding: via stranding element (aluminium film)
- AWG: 26/7
- Sheath material: PUR
- Outer diameter: approx. 7.8 mm
- Colour: green, similar to RAL 6018
Features
- Impedance: 100 Ħ
- EMC version: yes
- UL style: yes
- Temperature range: -10°C to +70°C
- (during operation)
- Pin assignment: EIA/TIA 568-A
- Halogen-free: in accordance with IEC 60754-1
Technical Details
- Measures
- Cable length
- 2 m
- General
- < >Colour GreenDesign Category 6aAssembly SF/FTPCable type 4x2 AWG 26/7Technology schleppkettentauglichInner conductor material CU (Kupfer)Type
- Patch cable
- Implementation
- < >Halogen Free YesCable cross section 7.8 mmType of connector
- RJ45, Cat.6A
- Other
- < >Temperature range -10 ... +70Specification
- Belegung nach EIA/TIA 568A
- Manufacturer specifications
- < >Manufacturer TTL NETWORKFactory number 1842-SK-2,0MPackage weight 0.151 kgRoHS conformEAN / GTIN
- 9900002628619
