Fiiberoptiline võimsusmõõtur 850/1300/1310/1550nm

Tootekood: HS15-MESS
EAN: 4049759175320
Kaubamärk:
Ühik: tk
Laoseis: Tellimisel
Hind: 374,09 €
tk
 Lisa korvi

ARTICLE INFORMATION

Fiber Optic Power Meter for measurement of the Insertion Loss of Fiber-Communication links. The unit is used with the Light Sources HS15-LS1 (850nm/1300nm) and/or HS15-LS2 (1310nm/1550nm).

Specifications:
Robust and compact case
Internal storage for 39 measurements
Data transfer through with PC is possible
Communication Connector: USB
Visiual Fault Locator included in the unit
Detector Type: InGaAs
Visiual Fault Locator: 1mW
Optical Connector: SC/ PC
Measurement Range: +8dBm ~ -70dBm
Measurement Wavelength: 850nm, 1300nm, 1310nm, 1550nm
Resolution: 0,01dB
Accuracy: +/- 0,2dB
Modulation Detection: 270Hz, 1kHz, 2kHz
Low Battery Warning
Display Backlight
Operation Temperature -10°C ~ +60°C
Opteration Humidity < 90% RH
Storage Temperature -20°C ~ +70°C
Storage Humidity < 90% RH
Power Source: 2x AA/LR6 1,5V (not included)
Dimensions: 170x97x38mm
Weight: 330g

PRODUCT FEATURES

  • Measured value memory
  • True
  • Type of indication
  • LCD/monitor
  • With PC/printer interface
  • True
  • Suitable for network protocol measurement
  • False
  • Available Connector
  • SC;LC
  • Power
  • 2 x AA
  • Dimension
  • 170 x 97 x 38 mm
  • Net weight
  • 330 g
  • Operating temperature
  • -10 – 60 °C
  • Storage temperature
  • -20 – 70 °C
  • Wave length
  • 850 – 1550 nm
  • Output power
  • 1 mW
  •
  •
